Creasol DomBus33 - Smart light controller, with 3 relay outputs, 3 AC inputs, 5 I/Os

DomBus33 is a DIN-RAIL module, 54mm wide, designed to control an existing lighting system with 3 lights using 115/230V pushbuttons and step-by-step relays.





DomBus33 has 3 relay outputs, that can be used to send pulses to existing step-by-step relay coils to switch lights ON/OFF, 3 AC inputs to be connected to the step-by-step relay contact to know the ON/OFF light status, and 5 low-voltage I/Os that can be connected to additional pushbuttons and/or switches to activate/deactivate single lights, or activate/deactivate all lights (useful to turn all lights OFF when leaving home).
In this way lights can be controlled by both existing pushbuttons and domotic controller (smartphone, web interface, automation, scenes, groups).

To simplify wiring, the terminal block has 3 terminals for relays, 3 for AC inputs, and 1 terminal for the common (usually Neutral, but Line can be used as well): in this way it's easier and faster to connect the module to the light system. Please take care to connect only loads that are protected by the same RCCB (circuit breaker).

As other DomBus modules, all ports can be configured in many different ways, and also this module supports DCMD, commands sent to the same or other modules to perform simple actions, that permit to achieve high reliability (DCMD commands work even if domotic controller is not operational) and easy programming (don't need to create automations in the domotic controller, just configure DomBus ports to perform actions on events). Last, but not least, as other DomBus modules it's optimized to get low power consumption, less than 10mW normally (0.75mA @13.6V) and less than 150mW when all relays are ON (10mA @13.6V).

Features

  • 3 relay outputs, 250Vac 5A max, with overvoltage protection (varistors)
  • 3 AC inputs, 110-230V, to monitor voltage on loads
  • 1 common (Neutral or Line) for both relays and AC inputs, to simplify connections
  • 5 programmable I/Os
  • 8-25Vdc power supply
  • 10mW power consumption
  • 150mW max power consumption
  • 52x89x65mm



DomBus32, Domoticz relay module

Relay module for DomoticzModule Relay Domoticz Home Automation System



Application notes

Home automation system and existing light plant - Controlling lights by smartphone with PIRs




For any questions, suggestions, feature requests, contact us by Telegram, group DomBus.

DomBus installation block chart

Installation schema
Often it's important to have a stable power to supply your Smart Home, to avoid troubles with the domotic controller (RaspberryPI or other), have internet connection always ON and are able to manage alarm sensors even in case of power outage.
  • Use a 12V power supply unit with backup battery charger, to avoid trouble on RaspberryPI or other devices. Also, in this way it's possible to get everything working even in case of power outage (domotic controller, domotic modules, network switches, routers, NVR and IPcams).
  • Use a 12V lead-acid battery well dimensioned to supply everything during blackout.
  • Use a DC/DC converter 12V → 5V 3A to supply the RaspberryPI, if you have it.
  • To use DomBus modules, use a standard alarm shielded cable (within 4 wires) to interconnect all modules to RaspberryPI (through a cheap RS485 to USB adapter).
  • Protect each bus with a fuse

Ports parameters

This parameter can be set only for the device named EV Mode
Parameter name Function
HWADDR=0xNNNN This command set new address for the dombus device: reload the Switch panel to see the new devices associated with the new address of DomBus. NNNN is an exadecimal number, from 0x0001 to 0xff00, so 65280 combinations are available. Keep note of address assegnated to each dombus device, because in case of address conflict it's needed to switch off one of the conflicting device and program the remaining one to another address, or make a factory reset as explained below.
INVERTED Used to invert the logic state of an input or output. Can be used in conjuction with OUT_DIGITAL, OUT_RELAY_LP, IN_DIGITAL, DIMMER.
Normally, domoticz switch is On if input is at logic level high (open), and Off when it's shorted to ground. If INVERTED is specified, domoticz switch will be On when the corresponding input is shorted to ground, and vice versa.
OUT_DIGITAL Output, open collector, active low, On => output wire is shorted to GND (max current 50mA). Off => output is open (current=0).
OUT_RELAY_LP Not recommended: output, open collector, active low, but with duty cycle 25% to reduce power consumption on relays coil
OUT_DIMMER Set the output as DIMMER, from 0 to 100% using 5% step, 500Hz frequency. Suitable to control LED strip lights
OUT_BUZZER Set two outputs as BUZZER: a piezo buzzer can be connected to the selected two ports (configured in push-pull) to generate 5KHz frequency when the corrsponding Domoticz switch is On. The Domoticz switch can be configured as selector: in this case buzzer will output 1 or more short alerts to notify a status, similarly to the led configured as OUT_DIGITAL with Domoticz switch configured as Selector.
OUT_BLIND

Port configured to control a blind, in close direction. Next port will be automatically configured as blind in open direction.
Ports OUT1 and OUT2 can directly be connected to 12V relay coils (if Vbus is 12-14V, or 24V relay coils if Vbus is 24V).
Ports IN1..IN3 can be configured as OUT_BLIND, but in this case should be connected to relayboard that already have a transitors/optocouplers to drive relays.

e/td>
OUT_LEDSTATUS Configure a LED port to show the device status (flashes when a frame is transmit to the RS485 bus)
OUT_ANALOG Set output as analog, with 0-10V linear output. It can be used to control another electronic board with 0-10V or 1-10V input (light dimmer, heat pump power, linear valve, ....).
The domotic controller will display a device with a slider, like dimmer, with values from 0 (=0V) to 100 (=10V).
Using Domoticz, it's possible to create LUA or dzEvent automations that automatically change the output voltage according to some inputs (brightness, temperature, renewable power availability, ...): the DAC value can be set using the syntax commandArray['DEVICE_NAME']='Set Level 74' to set the output voltage to 7.4V.
IN_DIGITAL Digital input, is On when the corresponding input is at high voltage level (open), and Off when the corresponding input is at GND (shorted).
IN_ANALOG Port configured as IN_ANALOG can be used to measure DC voltage, like battery voltage, bus voltage, thermistors and temperature sensors, .... The voltage is sampled every 15 seconds.
DomBusTH has one pad/hole where it's possible to solder a wire to measure an external DC voltage, <30Vdc; a solder jumper must be opened (because that pad is connected to Vbus).
Also, one or more of the 4 input wires can be configured as analog inputs, 0-3V range: a solder jumper in the PCB must be opened (by cutter) to disable the internal pullup resistor. Also, external resistive divider should be added to measure higher voltages, so the voltage at the input terminal block must be less or equal than 3V.
On DomBus12 it's possible to use IO7, IO8 and IO9 ports as analog inputs. Also, it's possible to use IO1, IO2, IO3, IO4 ports as analog inputs, but in this case it's needed to open, using a cutter, the corresponding PCB jumper PU1-PU4 (that internally connect the input line with a 10k pullup resistor): for example, to use IO1 as analog input, the PU1 PCB jumper must be open. Analog voltage must not exceed the 0-3V range: if voltage range is higher, a resistive divider must be applied externally.
On DomBus23 only IO1 and IO2 ports can be configured as analog inputs: only 0-3V range is supported, and a resistive divider must be externally connected to measure higher voltages.
IN_COUNTER Used to count pulses, max 16 pulses/second (57kW max using 1000pulses/kWh meter, or 28kW max using 2000pulses/kWh meter). This solution is perfect to count energy, gas, water, ...If TYPENAME=kWh is also specified in Description, a device with both energy and power will be created. Other options that can be set for this kind of device is OPPOSITE=dev to set the device counting energy in the opposite direction (import vs export), and DIVIDER=nnnn where nnnn is the number of pulses/kWh (default 1000, but can be 1666, 2000 or any reasonable value).
IN_TWINBUTTON This is a method to connect two pushbuttons/switches to a single input, to get a UP/DOWN/STOP select switch. The two switches are connected together by a 4.7KOhm resistor, using the schema indicated in the application notes below.
A For analog and distance sensors: used to compute the real value using the formula  REAL_VALUE=A * VALUE_FROM_DOMBUS + B.
B For analog and distance sensors: used to compute the real value using the formula  REAL_VALUE=A * VALUE_FROM_DOMBUS + B
For temperature, used to calibrate the value using the formula REAL_TEMPERATURE=MEASURED_TEMPERATURE + B
FUNCTION For analog input connected to a thermistor (NTC, for example), used to convert the read value to a temperature.
Supported types:
FUNCTION=3950 for NTC with Bcoeff=3950
Example: IN_ANALOG,FUNCTION=3950,B=-0.3 to use 3950 type NTC 10k@25°C, and calibrate offset -0.3°C.
First configure device as IN_ANALOG and then as IN_ANALOG,FUNCTION=3950
As FUNCTION parameter enable a conversion performed by the domotic controller (not inside the DomBus module), DCMD(Value:min:max) command can be added but min and max value should be the analog values in the range 0 (corresponding to input at 0V) and 65535 (corresponding to 3.3V)
DIVIDER Used with IN_COUNTER ports to set how many pulses per unit of measure. For example, using energy meter with 2000 pulses/kWh, the option DIVIDER=2000 should be set; in case of water meter with 20000 pulses/m³, DIVIDER=20000 should be set.
TYPENAME Option to force the creation of a the specified Domoticz. For example, IN_COUNTER,TYPENAME=kWh to create a energy/power meter instead of a normal incremental counter, or IN_ANALOG,TYPENAME=Temperature,A=0.123,B=-50 to get an analog input that return a temperature using the linear equation Temperature=A*x+B where x is the analog value read
OPPOSITE Used for kWh devices, measuring electric power and energy. Suppose to have a PowerMeter Import device, with Unit=98 (see Setup ⇒ Devices), measuring the power/energy from grid, and PowerMeter Export, with Unit=99, measuring the power/energy produced and fed to the grid. If these devices are connected to the pulse output of an energy meter, when a pulse is received from the Import device it means that exported power is 0, and vice-versa. This parameter is used to set what is the Unit number associated to the opposite counter.
So, PowerMeter Import description must have IN_COUNTER,TYPENAME=kWh,OPPOSITE=99 and PowerMeter Export description IN_COUNTER,TYPENAME=kWh,OPPOSITE=98
ADDR EVSE: used to set the Modbus address of a DDS238-2 ZN/S energy meter. By default DDS238 has address=1 and baud rate 9600. Setting ADDR=2 to set the Modbus to the specified value. On DomBusEVSE module, address 2 is used to measure charging power/energy, and address 3 to measure grid power/energy. Valid range from 2 to 5.
This parameter can be set only for the energy meter devices or M1 Addr device
MAXCURRENT EVSE: set the max charging current, that normally is limited by the cable used to connect the vehicle to the charging station. Valid range from 6 to 36, default value is 16 Ampere.
This parameter can be set only for the device named EV Mode
MAXPOWER EVSE: maximum power that can be drained from the grid (available power). Valid range from 1000 to 25000, default value 3300 Watt.
This parameter can be set only for the device named EV Mode
STARTPOWER EVSE: minimum available power to start charging: the minimum current is 6A, but usually the On-Board Charger charges less current than what is set, so maybe 900W is sufficient. Please note that charging at a low current lead to a poor efficiency (e.g. 30% power loss). Valid range above 800, default value 1200 Watt.
This parameter can be set only for the device named EV Mode
STOPTIME EVSE: time in seconds after which the charging process is stopped if the available power is less than what is drained by the car with the minimum current (6A). This parameter is used to prevent that, expecially in SOLAR mode, the charging is ended if no power is available for a short time. Valid range from 5 to 600, default is 90 seconds. Time is internally reduced /5 in case that imported power from grid exceed the MAXPOWER parameter, to prevent disconnections.
This parameter can be set only for the device named EV Mode
AUTOSTART EVSE: can be set to 0 or 1. 0 means that this function is disabled. 1 means that this function is enabled, and permit to restart automatically the last charging mode when the vehicle is plugged again to the wallbox. Default value is 1.
DISABLE Used to disable one or more ports: it can be usedful with large buses with more than 255 ports (devices), because Domoticz has a limit of max 255 devices for each bus. In this case it's possible to disable unused module ports by writing, in the Description of port 1, the list of disabled ports separated by colon, for example
DISABLE=2:5:6:7:11 to disable ports 2,5,6,7,11:16 (11 corresponds with port .b in hex and 16 with port .10 in hex) of the current module. Port 1 can be never disabled.
To enable a previosly disabled port, just edit the port 1 description for that module, removing the port from the list of DISABLE command: that port will be enabled again in 60 seconds (wait for 1 minute and reload the Domoticz panel).
DCMD Dombus Command: through this keyword it's possible to set a command to send to the same or another module, when an event occurs.
In this way, when an event occurs, the module send a command to a dombus module to execute an operation, and this work without the need of a Domoticz controller and without the need to configure Domoticz to manage this kind of actions. See the DCMD section below.

DCMD commands

This is an experimental function, undergoing testing and development, available on DomBusTH, DomBus12, DomBus23, DomBus31 modules.

For each port it's possible to configure, through the Domoticz Description field, one or more DCMD commands.

DCMD is a command that is sent to the same or to another DomBus module, in response to an event, and more DCMD commands can be specified for the same event and port.

The syntax is DCMD(Event:ValueLow:ValueHigh)=ModuleAddress.ModulePort:Command:Value

where ValueLow, ValueHigh, Value are optional parameters.
When ModuleAddress corresponds to the same module that we're editing, the command is executed locally, by the same module.
When ModuleAddress corresponds to another Dombus module, the command is sent by bus to that module.

DCMD: list of possible events
Event Description Example
OFF This even occurs when input goes OFF DCMD(OFF)=13.1:OFF
When input goes off, turns OFF also port 1 of module 13
ON This even occurs when input goes ON

DCMD(ON)=13.2:ON:90s
When input goes on, turns ON port 2 of module 13 for 90s

PULSE Input is pulsed ON for less than 0.5s DCMD(Pulse)=13.3:TOGGLE
When input is pulsed shortly, send command to module 13 port 3 to toggle it's output OFF->ON or vice versa
PULSE1 Input is pulsed ON for about 1s

DCMD(Pulse1)=13.3:ON
When input is pulsed for 1s, turns ON port 3 of module 13

PULSE2 Input is pulsed ON for about 2s

DCMD(Pulse2)=13.3:OFF
When input is pulsed for 2s, turns OFF port 3 of module 13

PULSE4 Input is pulsed ON for about 4s

DCMD(Pulse4)=13.4:ON:2h
When input is pulsed for 4s, turns ON port 4 of module 13 for 2 hours

DIMMER
VALUE Sensor value is ≥ ValueLow and < ValueHigh
Command is repeated every 30s if the comparison matches.

DCMD(Value:0:20.5)=13.5:ON
DCMD(Value:21:50)=13.5:OFF
Turns ON output 13.5 when temperature is below 20.5°C, and turns OFF when above 21°C

DCMD(Value:0:12.2)=31.7:ON
DCMD(Value:13.8:20)=31.7:OFF
Turns ON port 31.7 when the current voltage is below 12.2V, and turns OFF when voltage is above 13.8V

DCMD(Value:0:100)=31.8:OFF
DCMD(Value:1400:10000)=31.8:ON
Turns ON port 31.8 if exported power (from photovoltaic?) is ≥ 1400W, and disable when the exported power falls below 100W



DCMD: list of possible commands
Command Description Example
OFF Turns output OFF. If the optional Value is specified, output will be OFF for the specified time, then returns ON
ON Turns output ON. If the optional Value is specified, output will be ON for the specified time, then returns OFF
TOGGLE Change state to the selected output. If the optional Value is specified, wait the specified time before toggling output
DIMMER



Value optional parameter: list of possible values for the command
Command Description Example
number A number without any suffix should be multiplied by 31.25ms (seconds/32) 1=31.25ms
3=93.75ms
16=500ms
numberS Number of seconds, from 1 to 3600

1s=1 second
60s=1 minute
100s, ....



numberM

Number of minutes, from 1 to 1440 1m=1 minute
10m=10 minutes
180m=3 hours
numberH Number of hours, from 1 to 43824 1h=1 hour
6h= 6 hours
72h=3 days
numberD Number of days, from 1 to 1826

1d=1 day
....



Examples 1: configure a pushbutton switch to have 3 functions:

short pulse => toggle ON/OFF light
1 second pulse => enable ventilation for 30s
2 seconds pulse => disable ventilation

This 3 events can be configured writing in the description of the pushbutton switch:
DCMD(Pulse)=0101.1:TOGGLE, (with a short pulse, toggle port 1 of module 0x0101)
DCMD(Pulse1)=0101.2:ON:30m, (with 1 second pulse => turn on port 2 of 0x0101 for 30 minutes)
DCMD(Pulse2)=0101.2:OFF, (with 2 seconds long pulse, turn OFF the port 2 of 0x0101)

The Domoticz switch Description will be

IN_DIGITAL,INVERTED,
DCMD(Pulse)=0101.1:TOGGLE,
DCMD(Pulse1)=0101.2:ON:30m,
DCMD(Pulse2)=0101.2:OFF

Example 2: temperature sensor that enable/disable electric heater and valve

In the description field of the temperature sensor we'll write

DCMD(Value:0:20.5)=0101.3:ON, (if temperature between 0 and 20.5°C, turns ON heater on output 3 of module 0x0101)
DCMD(Value:0:20.5)=0102.1:ON, (if temperature between 0 and 20.5°C, turns ON valve output 1 of module 0x0102)
DCMD(Value:20.8:50)=0101.3:OFF
(turn OFF heater when temperature above 20.8°C)
DCMD(Value:20.8:50)=0102.1:OFF
(turn OFF valve when temperature above 20.8°C)
Domoticz temperature sensor Description will be:

TEMPERATURE,
DCMD(Value:0:20.5)=0101.3:ON,
DCMD(Value:0:20.5)=0102.1:ON,
DCMD(Value:20.8:50)=0101.3:OFF,
DCMD(Value:20.8:50)=0102.1:OFF



Installation

Using RS485 specific cables it's possible to get almost 1km linear bus with several devices attached. Alternatively, it's possible to use 2 twisted pairs of cheap Cat6 UTP or STP cable, one twisted pair for data (A and B) and one for 12-24V power supply. Ideally, all devices should be connected using a linear bus topology, to get the lowest reflection/noise, and connect 100-150 Ohm resistor on the two ends, as illustrated in the Fig. 2. In practice, this is not important for common buildings.

dombus connection

AN domoticz example2

At Raspberry/PC side, it's possible to use a cheap USB-RS485 adapter, if a serial port with RS485 driver is not already available.

Using DomBus modules it's possible to:

  1. avoid RF pollution
  2. no need to periodically change batteries on sensors/actuators
  3. using a UPS or  13.6V power supply with backup battery, it's possible to get a building automation system that works also in case of power outage
  4. very very low power consumption



Writing a microSD card with a fresh Raspbian + Domoticz distribution

Click here if you need to write a microSD card with a clean updated Raspbian+Domoticz image optimized to extend SD life (minimizing writings), and with some addons (firewall, backup, libraries).


Adding DomBus plugin to Domoticz

Linux version

This procedure is not needed in case of a new Domoticz installation writing the SD as written above.
If Domoticz does not already include the DomBus plugin, type the following commands (from Linux root shell: type sudo su - to become root):

#install git, if not already installed
which git
if [ $? -ne 0 ]; then sudo apt install git; fi

#change to the domoticz directory / plugins
cd /home/pi/domoticz/plugins

#fetch the Python Plugin Manager (that can be used to install/upgrade other plugins, including Creasol DomBus)
git clone https://github.com/ycahome/pp-manager

#fetch Creasol Plugin
git clone https://github.com/CreasolTech/CreasolDomBus

#restart Domoticz daemon
service domoticz restart

Windows version

FIrst python should be installed, following the instructions at www.domoticz.com/wiki/Using_Python_plugins.
Then you should create a plugins folder inside the domoticz directory, within another subfolder named CreasolDomBus: in this subfolder, copy files python.py and CreasolDomBusProtocol.py that you find in the GitHub repository github.com/CreasolTech/CreasolDomBus

Domoticz configuration

After plugins installation and Domoticz restart, it's possible to add the Creasol DomBus hardware (Setup->Hardware , add new "dombus" hardware type "Creasol DomBus" and specify the serial device, normally /dev/ttyUSB0) and connect the DomBus device to the RS485 bus.
DomBus module is factory programmed with a default address indicated above, and only one port will be automatically added to the Switches panel of Domoticz. Enter the Switches panel, find the new device with the DomBus default address, click on Edit and add in the description ,HWADDR=0x0001 to set the new address to 0001, or specify another address of your choice. Reload the Switches panel to see all input/output/led ports of DomBusTH active.

With Domoticz, each DomBus port can be configured via the Domoticz device description: for example a port IN_DIGITAL normally is On when it's left unconnected, and Off when it's shorted to GND, but it's possible to invert this function specifying in the device description the parameter INVERTED, separated by a comma (,): IN_DIGITAL,INVERTED . Relay outputs can be configured writing in the description field OUT_DIGITAL or OUT_RELAY_LP: in the latter case, relay are internally managed to assure a low power consumption.
Please check the sections Ports capabilities and Ports parameters.

Ports that are not used can be disabled in Domoticz Setup ⇒ Devices clicking on the blue arrow of each useless port (device), but in case of a bus with almost 255 ports, it's suggested to disable the unused ports by using the DISABLE command:
1. suppose that DomBus module 0x0001 has ports 3,4,5,6,8 not used
2. in Domoticz Switches panel select port1 of that module ([0001.1] RL1)
3. click on Edit, and add in the Description field DISABLE=3:4:5:6:8 and click on Save.
In this way, the selected ports will be disabled and removed from the Devices list. With this solution it's possible to add more DomBus modules to the same bus, with up to 255 enabled ports. In large buildings, it's a good practice to have more than one bus, to divide floors or areas.


Installing CreasolDomBus Home Assistant custom component

The integration code is available at https://github.com/CreasolTech/home-assistant-creasol-dombus
The following commands should be executed in the linux shell: for people using Windows, use git UI to download the custom component and place it in the right directory.
cd /tmp
git clone https://github.com/CreasolTech/home-assistant-creasol-dombus.git
cp -a home-assistant-creasol-dombus/custom_components HADIR/config/
ha core restart
where HADIR is the Home Assistant root dir: in case of Hassio, use the command cp -a home-assistant-creasol-dombus/custom_components /config/
After reboot of Home-Assistant, this integration can be added through the Configuration -> Integrations -> + ADD INTEGRATION and selecting Creasol DomBus integration.

FAQ about DomBus products

First, please note that:
  • You can connect up to 20-30 modules per bus: the max number of ports managed by Domoticz is 256, and you can use the DISABLE command to disable ports that are not used in case that 256 ports are not enough.
  • It's good to make different buses on large buildings with several sensors and actuators, for example a bus for the ground floor, one for the second floor, ... Any bus is connected to a RS485 port/adaptor and need a DomBus plugin for that serial port, so in the Domoticz Setup⇒Hardware, one Creasol DomBus line for each serial port.
  • DomBus modules are factory programmed with a certain address, for example 0xff12 for DomBus12, 0xff23 for DomBus23, and so on. As each device connected to the bus MUST have a unique address, add only one module to the bus then program its address using the command HWADDR=0x0001, then connect another DomBus module and program its address to 0x0002 and so on. Address can be chosen to identify floor and room, for example 0x1023 to identify floor 1, room 2, module 3 in that room.
How can I change address of DomBusTH device?
DomBusTH is factory programmed with address 0xff51 : please connect only 1 new/unprogrammed DomBusTH to the existing bus, and you'll find one "switch" device in the Domoticz Switches panel with name "dombus - [Hff51] OUT1" or something similar.
Click on the Edit button of that switch and add the following text to its description:  ,HWADDR=0x0001  (don't forget the comma used to separate each parameter) to set the new address to 0001, ot another not-used value.
DomBus device will be set to the specified address, then you'll find in the Switches panel all ports with the selected address.
At this point you can add another new dombus device, and change its address in the same way.
DomBusTH: how to mount and fix it?
DomBusTH electronic board must be fixed by a just 4 points of hot glue or mastic on the blank cover with a 3-4mm diameter hole in the center.
Please keep in mind that:
  1. sensor needs that air circulate easily, but the polymers inside it can be damaged by direct sun light and dust: for this reason the hole must be centered with the LEDs inside the board, and sensor must stay below the hole!
  2. when LEDs are steady ON: for this reason they must stay above the sensor, and air must circulate easily from bottom to top
  3. don't cover the programming pads, so it will be possible to further upgrade the firmware without removing the board from the plastic cover
DomBusTH: how to do a factory reset?
Normally, factor reset is not needed because, enabling debug on Domoticz controller, it's always possible to know the address of a device, changing its address, and for each port change it's configuration through the Domoticz web panel.
Anyway, it's possible to do a factory reset in this way:
  1. Disconnect the device
  2. For firmware version before 2021-11-11: Solder the PCB jumper a to force IN4 in low impedance (150 Ohm resistor)
  3. Connect together IN1, IN2, IN3, IN4 wires
  4. Connect the device to the power supply: you can see a red flash 1000ms long, that notify that configuration was restored to the factory default.
  5. For firmware version before 2021-11-11: If IN4 is used as input, remove the solder bump on PCB jumper a
Why buzzer does not work?
DomBusTH, DomBus12 and other DomBus modules supports the manage of piezo buzzer without oscillator.
For example it's possible to connect a piezo buzzer to DomBusTH IN3 and IN4 I/Os; with the solder iron tip make a short on the I/O PCB jumpers (marked as "a" and "b") corresponding to IN3 and IN4 to reduce the output resistance. Configure IN3 device as OUT_BUZZER (don't care about IN4).
If the buzzer does not work, maybe the buzzer has an oscillator inside: in this case connect the buzzer to a 12V source and if you'll hear a "TIC", it has not the oscillator inside, while if you hear a sound, the buzzer has the oscillator and can be connected to a relay or (even better) to an open-drain output: in the latter case, it can be connected between 12V and OUT1 (or OUT2); configure OUT1 as OUT_DIGITAL. To get the buzzer sending 1 or more beeps, following by a 4 seconds pause, set the Domoticz device as Selector Switch, enabling level 10, 20, 30, 40, ... corresponding to 1 beep + pause, 2 beeps + pause, and so on: the buzzer oscillator circuit must have a fast response to work in this way, because the supply time is very short, less than 100ms.
2 or more modules with the same address
In case that 2 or more modules have the same address, it's neccessary to disconnect the one that should keep that address, and change address to the other ones.
Example: module A has address 0x0002, module B has address 0x0002 instead of 0x0003, module C has address 0x0002 instead of 0x0004.
Disconnect module A and B (only C is supplied), then select any device with address 0x0002 (for example device with ID=2.1) and write in the Description field HWADDR=0x0004 to set the right address for module C.
The connect module B, select a device with address 0x0002 (device with ID=2.1) and write HWADDR=0x0003 in the description, to set the new address to module B.
Then connect module A that has the right address.
How many DomBus modules can I connect to a bus?
Domoticz has a limit of 256 devices (I/O) to a single hardware, and this correspond to 20-30 DomBus modules (it depends by the number of I/O/Sensors for each module).
It's possible to have more than one bus, each bus associated to one RS485 port: for example for large buildings or if it's needed to differentiate the buses to increase system security, it's possible to use many RS485/USB adapters connected to Domoticz, one for each bus.
How to split a bus in 2 buses in Domoticz?
If you have many modules connected to a bus and you want to split in two buses (maybe one for the ground floor, and one for the second floor?), you have to:
  1. split the bus, connecting the second bus to another RS485/USB adapter (better to use an adapter from another manufacturer, to avoid Linux exchanging the two serial ports)
  2. Setup⇒Hardware and create another hardware using Creasol Dombus plugin, specifying the new serial port
  3. Setup⇒Devices to list all dombus devices: sort by ID. You can see that all devices in the new bus are already active with the same configuration of the previous bus
  4. For each device moved to the second bus, click Edit⇒Replace to replace it with the new device in the second bus (you can find it with the default name): in this way device is moved to the second bus mantaining the state history (On/Off history, temperature history, Watt/Energy history, ....) and room plan position.
How to identify a RS485/USB adapter when more than one are connected
Assuming to use Linux (Debian, Ubuntu, Raspbian, ...), it may happen that more RS485/USB adapters are connected to the same computer, and it's important to identify the serial port in a persisten way to avoid troubles: if they have the same vendor id, product id and serial number, you have to follow the step-by-step procedure: assuming that ttyUSB0 is used as dombus #1, and ttyUSB1 as dombus #2
  1. find the devpath for the bus #1, corresponding with ttyUSB0 in this example, running the command udevadm info -a /dev/ttyUSB0|egrep 'ATTRS.(idVendor|idProduct|devpath)'|head -n3
    Assuming that result is
     ATTRS{devpath}=="1.5"
     ATTRS{idProduct}=="7523"
     ATTRS{idVendor}=="1a86"
  2. create/edit the file /etc/udev/rules.d/99-serial-ports.rules adding the line
    SUBSYSTEM=="tty", ATTRS{idVendor}=="1a86", ATTRS{idProduct}=="7523", ATTRS{devpath}=="1.5", SYMLINK+="ttyUSBdombus1"
    to set that the USB/RS485 adapter plugged to the USB port 1.5 should be named /dev/ttyUSBdombus1
  3. Make a symlink using the command ln -s /dev/ttyUSB0 /dev/ttyUSBdombus1
    This is needed now because the system is running with the adapter already plugged.
    When the computer will reboot, the USB-RS485 serial adapter plugged to the port 1.5 will assume the device /dev/ttyUSBdombus1
  4. Enter the Domoticz UI, Setup ⇒ Hardware, select the dombus1 hardware and change serial port from /dev/ttyUSB0 to /dev/ttyUSBdombus1, then click on Update button.
  5. Repeat the steps above for the next RS485/USB serial adapters, to set the device to ttyUSBdombus2, ....
All DomBus devices have been duplicated!
This is caused by two running dombus instances using the same serial port!
Most probably you have selected the DomBus plugin in Setup⇒Hardware , and clicked to the Add button instead of Update button.
Now you have to select the duplicated DomBus plugin, disable it, click Update, then select it again and click on Delete button.
I have many USB-serial adapters
In case of many USB-serial adapters, during boot you can have that kernel assigning a different name than before. Device that before was named ttyUSB0 may be renamed, after reboot, ttyUSB1 or ttyUSB2. To get a persistent name assigned to each adapter, follow the instructions at https://www.domoticz.com/wiki/PersistentUSBDevices.
Why there is a long delay between pushing a button and get light/output on?
Some possible problems that lead to long latency are:
  1. bus is not terminated by resistors: RS485 is a balanced bus, and need two resistors 100-150 ohm connected to the two opposite end of the bus.
    RESISTOR --- Module1 --- Module 2 --- Raspberry --- ..... --- Module 20 --- Module 21 --- RESISTOR between A and B
    Some DomBus modules have a PCB jumper that can be shorted (using a solder iron) to enable the RS485 resistor already included in the module.
    There must be exactly 2 resistors connected on the bus!
  2. Latency can be caused by Domoticz being busy with other services. Disable hardware that is not used or not needed, like Python Plugin Manager that is known to cause longer latencies. Also, enable logging so you can check exactly what is the latency reason (Domoticz reading the Raspberry internal sensors/cpu usage/disk usage, for example).
  3. Update DomBus plugin to the last version: you can install/enable Python Plugin Manager, update all python plugins (including Creasol Dombus) and then disable it.
Why DomBus device does not work?
1. Are you using Domoticz? Does Domoticz work?
2. Did you installed the Creasol DomBus plugin on Domoticz? If not, check the Configuration section above
3. If you open the Domoticz web panel, and enter Settings -> Hardware, can you find the Creasol DomBus protocol ? Did you enable it? If not, check the Configuration section above
4. When you connect the DomBus device to the RS485 bus, can you see a new device in the Domoticz Switches panel? if not, the device cannot communicate to Domoticz by RS485 serial bus. In this case, check that:
  a) DomBus device is supplied by 12Vdc or similar voltage
  b) RS485 bus is connected (A, B, GND) to Domoticz (Raspberry or other hw) through the USB/RS485 adapter or other RS485 adapter
  c) Verify that the DomBus protocol on Domoticz is configured correctly (115200bps and right serial device), and that there are not 2 DomBus hardware with in Domoticz with the same serial port
One DomBus module stopped working
If in Domoticz the ports associated to that module are shown in red, last update has happend more than 15 minutes ago: this means that the module has stopped sending its status to the domotic controller.
a) Check that 12-24V is applied between Vbus (+) and GND (-)
b) Check that A and B data lines (RS485 bus) are connected: with a voltmeter it's possible to test the voltage between GND and A, and between GND and B: these voltage must be almost the same(100mW difference) and in the range 1÷(Vbus-1) Volt.
c) check for led activity on DomBus module: periodically it has to transmit data to the domotic controller. If the module has at least one input, toggle the input LOW and HIGH and check that led flashes (to indicate a transmission). If it flashes, the module works. Check that in the home automation system that input changes it's state: if it changes, the domotic controller receives correctly. If the module has no inputs (like DomBus31), turn off and on the power supply: after few seconds you should see red flashing.
c) Now check the domotic tranmissions: toggle a module output and check that, everytime you toggle that output from the domotic module, the DomBus led flashes (indicating the transmision of acknowledge: if it does not flash, maybe the RS485 driver is broken (chinese RS485-USB adapters are very weak: you should replace it or replace the MAX485 chip inside).
Why current consumption is 0uA?
DomBus devices have a serie protection resistor, 2.2 Ohm, acting as a fuse when the user forget to protect 12V power supply by a fuse. Maybe the resistor is burned (you can check using an ohm-meter) and can be replaced by another resistor or, if you know what you do, by a short circuit.
DomBus1: first version of DomBus1 was not protected against polarity inversion, and switching mode power supply circuitry break down in case of polarity inversion opening the circuit. If you have a solder iron, you can try DomBus1 connecting a 5Vdc power supply to +5V indicated by the red arrow, and GND terminal block. Click to see the picture!
DomBusTH: Check polarity: the first wire (black) is ground (0V) and the second wire (brown) V+ (normally, +12V). DomBusTH is protected against polarity inversion.

DomBus software ChangeLog

2022-11-16 Rev02g5
OUT_RELAY_LP: to avoid relay coil noise, increased switching frequency to 20KHz
OUT_ANALOG_LP: increased frequency according to the modification above.
2022-11-04 Rev02g4
Added DCMD VALUE command for VOLTAGE, IMPORT and EXPORT ENERGY. Value must be positive.
2022-10-22 Rev02g3
Added firmware for DomBus34
Added transmission of power (watt) without energy.
DBEVSE: added virtual device "Grid Power"
2022-09-26 Rev02g
Added support for the new version of DomBusEVSE (charging station for electric vehicles)
Added support for MODBUS energy meter DDS238
Improved communication: limited length of ACK frames (only port and subcmd/arg1 in the payload); also, ACK are transmitted before CMD.
2022-02-07
LedSelect: now blank between flashes was reduced from 4s to 2s
COUNTER: periodically transmit status every 256 seconds, in case of no activity, to avoid bad graphs on Domoticz (graph should stay at zero, if no activity)
DomBusEVSE: new project
2021-12-02
DomBusTH: now factory reset can be done connecting IN1-IN2-IN3-IN4 together before power-on, without the need to configure IN4 as output (by shorting "a" pcb jumper).
2021-10-25
IN_COUNTER has changed: now it outputs two 16bit incremental counters: updated counter, and last counter processed by the domotic controller (confirmed by an ACK from the controller): in case that the domotic controller is offline (stopped or while booting), no pulses are lost, but they are accumulated and sent as soon as the controller return online. The max number of accumulated pulses is 65535: in case that more than 65535 pulses were received while controller is down, the counter is freezed to 65535.
2021-10-19
Improved IN_COUNTER ports: debouncing has been disabled (to works well with power meters with 2000 pulses/kWh).
DCMD(On) and DCMD(Off) commands now are available also for output ports, so when an output has been activated/disactivated, a DCMD command is sent to the same module (this can be useful to get two relays activated together, simultaneously, by a unique command) and/or to other modules.
2021-03-16
Added IN_COUNTER type, used to count pulses from electric meter, gas meter, water meter, .... Max pulse frequency = 5Hz (input is debounced), min transmission period = 5s (accumulate pulses if frequency is greater than 0.2Hz, to avoid high CPU usage by Domoticz.
Added TYPENAME=kWh option, to get an electric Power/Energy meter: this device computes both energy (proportional to the number of pulses) and power (frequency of pulses).
Added OPPOSITE=Unit option, associated to kWh devices (power/energy meters): when the opposite device receives a pulse, power for the current device is immediately set to 0 Watt
For example: PowerMeter_Import, with Unit=98. PowerMeter_Export, with Unit=99
On PowerMeter_Import description, add ,OPPOSITE=99, and in PowerMeter_Export description add ,OPPOSITE=98 : in this way when a pulse is received from the import device, the power on export device will be set to 0, and viceversa.
After powerOn, the module transmits its firmware version and module name, logged by Domoticz with priority INFO.
When device is supplied, it transmits its module name and firmware version so it can be logged by Domoticz.
DCMD commands now are transmitted before sending commands to the controller, to reduce latency.
2020-12-28
New protocol V2, with both destination and source addresses, and cmdLen field divided by 2 (to address up to 14 bytes for each command).
New DCMD_CONFIG and DCMD commands to get dombus commands (command from module to module).

Need help? join the DomBus channel on Telegram!
Esiste anche il Canale Telegram in Italiano DomBus_it!

Facebook domoticz groups:
Domoticz community, Domoticz Italia, Domoticz France, Domoticz Nederland, ... just search Domoticz on Facebook!

FaLang translation system by Faboba
